ZONESUN ZS-AFC36 Small Bottle Liquid Filling and Capping Machine Monoblock Cam System for Solvents Labs and Compact Production Lines

DESCRIPTION

This monoblock machine utilizes a cam-driven system to achieve speeds of up to 30 bottles per minute, delivering high-precision filling for small-volume liquids such as solvents. Its compact design allows seamless integration with a bottle labeling system, enabling streamlined and automated production. Ideal for laboratories and small-scale operations, it combines reliability, efficiency, and space-saving versatility.

Parameter

• Machine Model: ZS-AFC36
• Voltage: 110/220 V 50-60HZ 2 KW
• Filling Range: 0.2-200 ml
• Filling Pump: Ceramic Pump
• Working Capacity: 20-35 BPM(Based On Filling Range)
• Suitable Bottle Size: φ=10 mm*H=45 mm (Customizable)
• Suitable Cap Size: 12-30 mm(Customizable)
• Filling Accuracy: ±0.5 %
• Air Pressure: 0.5-0.7 Mpa/cm²
• Machine Material: SUS304
• Machine Size: 1750*1400*1800 mm / 68.9*55.12*70.87 inch(L*W*H)
