ZONESUN ZS-RIP1 Rotating Inkjet Printing Machine for Curved Surfaces

Description

The ZONESUN ZS-RIP1 Rotating Inkjet Printing Machine is designed for high-precision printing on curved surfaces such as bottles, tubes, and vials. Equipped with a TIJ hot foaming nozzle and a speed adjustable rotating system, it enables seamless wrap-around printing with consistent clarity. Its compact metal body, multilingual interface, and dual-direction rotation make it ideal for small-scale industrial applications requiring expiry date coding, logo marking, or batch identification on cylindrical products.

Parameter

• Product Name: ZS-RIP1
• Printed Object Type: Curved products
• Machine Dimensions: 610 × 330 × 340 mm
• Platform Dimensions: 300 × 300 × 145 mm
• Net Weight: 7.25 kg
• Rotation Direction: Clockwise / Counterclockwise
• Rotating Length: 5–22 mm/min
• Screen Size: 4.3 inch
• Printing Distance: 2–5 mm
• Printing Height: 2–12.7 mm / 2–25.4 mm
• Print Speed: 60 m/min (Max 90 m/min)
• Voltage: 110V / 220V, 50–60 Hz
• Ink Volume: 42 ml (approx. 800,000 characters)
• Ink Colors: Black / Blue / Green / Red / White / Yellow / Invisible
• Printable Content: Numbers / Bar codes / Codes / Characters / Patterns
