DESCRIPTION

The ZONESUN ZS-XG16E is a fully automatic dropper capping machine designed to streamline bottle handling and capping for small cosmetic and essential oil containers. It feeds droppers, inserts them precisely, and tightens caps in a continuous cycle. The vibratory bowl system can be tailored for different dropper styles, offering high adaptability. Ideal for production lines handling nail polish, serums, and essential oils.

PARAMETER

Machine Model ZS-XG16E
Bottle Height 30–300mm
Cap Diameter 18–70mm
Bottle Diameter 20–160mm
Working Speed 20–60 bottles/min (varies by bottle and cap size/shape)
Working Voltage AC 220V / 110V, 50–60Hz
Working Pressure 0.4–0.6MPa
Machine Size Approx. 1930 × 740 × 1600mm
Package Size Approx. 1970 × 990 × 1740mm
Net/Gross Weight Approx. 150kg / 334kg

PRODUCT DETAILS

CONTROL PANEL

PLC controls, English version

FEEDING

Automatically feed the cap, with a speed regulator.

CAPPING

Used for sealing various kinds of screw caps, like twist-off caps and flip-off caps.

ROBOTIC ARM

Automatically hold the caps and drop them into the bottles.

CONVEYOR

Large capacity, stable and efficient.
