ZONESUN ZS-VTGF2 Servo Gear Pump Viscous Liquid Tracking Filler
ZONESUN ZS-VTGF2 Servo Gear Pump Viscous Liquid Tracking Filler
Precio habitual
$11,999.00 USD
Precio habitual
Precio de oferta
$11,999.00 USD
Precio unitario
por
Los gastos de envío se calculan en la pantalla de pago.
No se pudo cargar la disponibilidad de retiro
Description
The ZS-VTGF2 is a high-performance servo-driven filling machine designed for viscous liquids such as lotion, soap, and detergent. Its dual nozzles track bottle movement during filling, ensuring precise volume control and minimizing waste. Ideal for medium to large-scale production, this system combines speed, accuracy, and intelligent automation in a compact footprint.
Parameter
- Machine model:ZS-VTGF2
- Power supply:110/220V 50-60HZ 5KW
- Filling pump:Gear Pump
- Filling range:100-3000ml
- Bottle size:H=80-180mm W=15-120mm
- Working speed:About 20-80 bottles/min (2 heads)
- Filling accuracy:About ±0.5%
- Air pressure:About 0.5-0.8MPa
- Machine size:About 2900*1400*1980mm(L*W*H)
- Machine weight: About 390kg
